TECHNICAL DOCUMENTATION PDF

-EPM MUELLER ® HIP Stem Extractor AU-S2

-EPM MUELLER ® HIP Stem Extractor CC.AU-S2    ( NEW 2019 )

-EPM MUELLER ® HIP Stem Extractor CFH.AU-S2   ( NEW 2019 )

-EPM MUELLER ® HIP Stem Extractor AU2

-EPM MUELLER ® HIP Stem Extractor CC.AU2,       ( NEW 2019 )

-EPM MUELLER ® HIP Stem Extractor CFH.AU2       ( NEW 2019 )

-EPM MUELLER ® HIP Stem Extractor S2

-EPM MUELLER ® HIP Stem Extractor CC.S2          ( NEW 2019 )

-EPM MUELLER ® HIP Stem Extractor CFH.S2        ( NEW 2019 )

-EPM MUELLER ® Anterior Approche Stem Extractor SA

-EPM MUELLER ® Anterior Approche Stem Extractor SA2   (NEW 2018)

-EPM MUELLER ® Anterior Approche Stem Extractor CO.SA2   (NEW 2019)

-EPM MUELLER ® Anterior Approche Stem Extractor CFH.SA2   (NEW 2019)

-EPM MUELLER ® Modular neck Stem Extractor MO

-EPM MUELLER ® Modular neck Stem Extractor CC.MO     (NEW 2019)

-EPM MUELLER ® Stem Extractor M6                 for stems with M6 thread

TECHNICAL DATA for the EPM MUELLER ® Stem Extractor AU-S2, AU2, S2:

-Instrument can be used with the following tapers: Æ 8 - Æ 16,

-Striking weight: 1.0kg (2,2 lb) standard; 1,7kg (3,74 lb)

-Total weight: 2,2 kg (4.84 lb) with 1,0kg Striking weight, ( AU2 or S2 )

-Total length: 550mm (21,7 inches) standard; 635mm (25 inches) long

-Hitting distance: 205mm (8.1 inches) standard; 275mm (8.08 inches) long

VARIANTS for the EPM MUELLER ® Stem Extractor AU-S2, AU2, S2:   -standard                                                          -long ( L )                                                              -heavy ( S ) with 1.7 Kg weight                              -long and heavy (L.S )

the EPM MUELLER ® femural stem extractor,has been succesfully used since 1993 in more than 1550 orthopaedic centers, mostly in Germany.

The 2 head types ( closed AU and oppen S),   enable extraction of allmost all stem types               ( including monobloks ) with tapers from 8 mm to 16 mm.

TECHNISCHE DOKUMENTATION PDF

-EPM MUELLER ® Hüft Schaft Extractor AU- S2                                                                           -EPM MUELLER ® Hüft Schaft Extractor       CC.AU-S2               ( NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor        CFH.AU-S2       (NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor AU2                                                                                     -EPM MUELLER ® Hüft Schaft Extractor CC.AU2                  ( NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor CFH.AU2         (NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor S2                                                                                       -EPM MUELLER ® Hüft Schaft ExtractorCC.S2                     ( NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor CFH.S2             (NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor AE2         ( ABC Schaft Ausschläger )

-EPM MUELLER ® Anterior Zugang Stem Extractor SA

-EPM MUELLER ® Anterior Zugang Stem Extractor SA2   ( NEU 2018)

-EPM MUELLER ® Anterior Zugang Stem Extractor CO.SA2   (NEU 2019)

-EPM MUELLER ® Anterior Zugang Stem Extractor CFH.SA2   (NEU 2019)

-EPM MUELLER ® Modular Hals Stem Extractor MO

-EPM MUELLER ® Modular Hals Stem Extractor CC.MO     (NEU 2019)

-EPM MUELLER ® Hüft Schaft Extractor M6           für Schaft mit M6 Gewinde

TECHNISCHE DATEN für EPM MUELLER ® Hüft Schaft Extractor AU- S2; AU2; S2; AE2

- Konusgrössen : Æ 8 – 16 mm                             - Schlaggewicht: 1.0 kg; 1,7 kg                              - Gesamtgewicht: 2,2 kg mit 1kg Schlaggewicht; 2,9 kg mit 1,7 kg Schlaggewicht                                  - Gesamtlänge: 550 mm (Standard); 620 mm (Lang) - Schlagweg: 155 mm (Standard) ; 225 mm (Lang)

VARIANTEN für EPM MUELLER ® Hüft Schaft Extractor AU- S2; AU2; S2; AE2

- standard                                                             - lang  ( L )                                                            - schwer ( S )                                                        - lang und schwer ( L.S. )

Der EPM MUELLER ® Hüft Schaft Extractor, Ausschlaginstrument für Hüftprothesen ist sei 25 Jahren in über 1550 Kliniken und Krankenhäuser erfolgreich im klinischen Einsatz in Deutschland und zunehmend im Ausland.

Durch die 2 Spannrahmenvarianten ( offen und geschlossen )  werden  fast alle Typen von Femurprothesen ( auch Monoblock )  mit Konus von 8 bis 16 mm, bei eine Revisionsoperation mühelos entfernt .
